Fuel Cell Graphite Bipolar Plate

Harog Technology has applied for more than 70 related patents in the field of fuel cells. The ultra-thin graphite bipolar plate for vehicles has a web thickness of 0.3mm, resistant to high temperature, high pressure and strong acid, service life >30,000h. Besides, we have air-cooled graphite bipolar plates for low-power products, which are currently being used in drones, two-wheelers, forklifts and other scenarios.

Availability:



Inquire Add to Basket

Product Description

· Special plugging process and exclusive formulation of graphite modifier to ensure zero leakage under operating conditions for more than 20,000 hours

· Special surface processing technology to ensure contact resistance ≤ 5mΩcm²

· Exclusively designed and developed large-area bipolar plate, the power per liter is greatly improved

· Light milling process, the plate can be as thin as 0.5mm (milling on one side)/0.8mm (milling on both sides)

Core Indicators of Harog's Graphite Bipolar Plates

Technical Parameter	Unit	Data	Remark
Density	g/cm³	≥1.9
Specific Resistance	μΩm	≤10
Flexural Strength	Mpa	＞60
Compressive Strength	Mpa	＞130
Shore Hardness	HSD	＞70
Safety Thinnest Site	mm	≥0.35
Air Leakage Velocity (@220kpag)	Sccm	＜0.1	full inspection
Contact Resistance	mΩ·c㎡	≤5
Glycol Cooling Compatibility	/	A	A-E
Acid Resistance	/	A	A-E
Metal Ion Content	ppm	≤50
Operation Life	h	＞30,000
Long-term Working Temperature	℃	-40~180
5000 Hours Power Attenuation	%	＜2%	Thinnest Site 0.4mm
